UIAutomatorViewer for Automated Android Tests

Question 1

Setting up UIAutomatorViewer

Answer

Setting up UIAutomatorViewer is easy as it comes with the Android SDK. It is located under the tools directory as a file called uiautomatorviewer.bat.

Once the program is started, you can click the screenshot button to indicate that you want to see a live view of the app currently running on the device. Once the live view appears, a sidepanel on the right will show a hierarchy view of the components that make up the current screen.

Question 2

How do I locate elements using UIAutomatorViewer?

Answer

The right side panel of UIAutomatorViewer will contain a hierarchical view of the current application's layout structure. As you click some of the items in the panel, you will see the properties for each of these items.

Properties such as content-desc, class, resource-id and text can be helpful to construct locators which you can use in your automated Appium tests.

For example, you have a layout with a button that you want to click. You use UIAutomatorViewer to inspect the button and see that it has these properties:

content-desc: myButton
text: my-button
resource-id: com.testingbot.test:id/mybutton
class: android.widget.Button

We can now construct several locators that will each target the same element, using different selector strategies. Each of these locators can be used in an Appium test.

Using content-desc (AccessibilityId)

The content-desc attribute can be used as an AccessibilityId:

driver.findElementByAccessibilityId("myButton");

Using text

The text attribute can be used as a name:

driver.findElement(By.name("my-button"));

Using resourceId

The resourceId attribute can be used as an id:

driver.findElement(By.id("com.testingbot.test:id/mybutton"));

Using class

The class attribute can be used as a className:

driver.findElement(By.className("android.widget.Button"));

Question 3

Using UIAutomatorViewer with TestingBot

Answer

Using UIAutomatorViewer allows you to find the locators you need for your tests.
You can make sure your test automation stays functioning by choosing the right locators. The right locators are the most simple locators, which are not likely to change during the lifetime of the app.
For example, instead of choosing a resourceId, it might make more sense to assign the element a specific AccessibilityId which will not change.
